CNC Vertical Turning Machine
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler, Trader, Distributor |
| Weight | 100-1000kg, 1000-2000kg, 2000-3000kg, 3000-4000kg |
| Voltage | 110V, 380V |
| Condition | New |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Power
1-3kw, 3-6kw, 6-9kw
Driven Type
Electric
Warranty
5years
Standard Feature
- Table With manual 4-jaws Chuck as Specification
- Automatic Lubrication System
- Work Light
- Coolant System With Motor, Tank, Piping etc
- Complete Splash Guard
- Telescopic Covers & Bellows
- CNC System
- Variable Frequency Drive (VFD) For Table
- All Casting’s Machining On CNC Machines
Optional Accessories
- Moving Cross Rail
- AC For Control Cabinet
- Chip Conveyor
- Hydraulic Chuck
- Extend Travel Of Ram
- Grinding Attachment
- Angular Milling Attachment
- Live Spindle With C-Axis
- ATC
- Extra Day Light
- Coolant Through Spindle
- Jig & Fixtures
- Linear Scales for X/Z axis
Details
| Descriptions | DSMM-1 | DSMM-1.25 | DSMM-1.6 | DSMM-2 | DSMM-2.5 | DSMM-3 |
| Capacity | ||||||
| Table Diameter (Manual Chuck) | 1000 mm | 1250 mm | 1500 mm | 2000 mm | 2500 mm | 3000 mm |
| Max. Turning Diameter | 1200 mm | 1600 mm | 1800 mm | 2200 mm | 2700 mm | 3200 mm |
| Max. Turning Height | 600 mm | 1000 mm | 1200 mm | 1200 mm | 1200 mm | 1200 mm |
| Max. Work piece Weight | 3500 Kgs | 4500 Kgs | 6000 Kgs | 8000 Kgs | 12000 Kgs | 15000 Kgs |
| Table | ||||||
| Range of Table Speeds | 5-300 rpm | 4-240 rpm | 4-240 rpm | 3-180 rpm | 2-120 rpm | 1.3-80 rpm |
| Change Gear Speed | 2-Steps | 2-Steps | 2-Steps | 2-Steps | 2-Steps | 2-Steps |
| Travel | ||||||
| X Axis Rapid Rate | 6 M / min | 6 M / min | 6 M / min | 6 M / min | 6 M / min | 6 M / min |
| X Axis Horizontal Travel | +600 mm-200 mm | +750 mm-250 mm | +950 mm-250 mm | +1050 mm-300 mm | +1350 mm-300 mm | +1750mm-300 mm |
| Z Axis Rapid rate | 6 M / min | 6 M / min | 6 M / min | 6 M / min | 6 M / min | 6 M / min |
| Z Axis Horizontal Travel | 600 mm | 900 mm | 900 mm | 1200 mm | 1200 mm | 1200 mm |
| Electric Motor | ||||||
| Spindle Motor (Kw) | AC 22/37 | AC 37/45 | AC 37/45 | AC 45/55 | AC 45/55 | AC 55/65 |
| CNC Contro | FANUC / SIEMENS | |||||
