Radial Drilling Machine


Radial Drilling Machine

MOQ : 1 Piece(s)

Product Details

Drilling Capacity (steel) 40 mm
After-Sales Service Provided Spare Parts
Brand Name DSMM
Driven Type Electric
Power 1-3kw
Voltage 380V
Weight 100-500kg
Certification CE Certified
Type Automatic

Yes! I am interested

Submit Your Requirement


Technical Specification

<

   Model 25mm 32mm 40mm 50mm
Drilling capacity in steel 25mm 32mm 40mm 50mm
Maximum distance from spindle to column 24" 32" 34" 48"
Minimum distance from spindle to column 10" 12" 13" 18"
Maximum distance from spindle to base plate 30" 34" 42" 50"
Minimum distance from spindle to  base plate 0" 0" 0" 0"
Diameter of column 6" 7 1/2" 9" 10"
No. of spindle speeds 4Single 3Single 4 * 2 (with two 3Single speeds 3Single
  4Double  3Double gear box 3 Double) 3Double
Range of spindle speeds 80-700RPM 80-700RPM 60-700 RPM 50-700RPM
Working surface of base plate 9" 11" 13" 15"
Travel of spindle 6" 8" 9 1/2" 12"
Spindle morse taper No. 3 4 4 5
Vertical Adjustment of arm 15" 18" 21" 24"
Over all height 60" 70" 78" 90"
Arm till to any angle upto 90" 90" 90" 90"
Floor space required 40" * 24" 44" * 25" 55" * 30" 65" * 40"
Nett weight approximate 6Qntls 9Qntls 15Qntls 25Qntls
Electricals Motor required 1H.P. 2H.P. 3H.P. 5H.P.
Price Rs. Rs. Rs. Rs.
